Angle Grinder

Brand: Nowicki


Product Description:

Designed for grinding fresh and frozen meat down to -20 to required granulation and making other technological operations depending on used equipment.

l  Two compatible drives of feeding worm and pressing worm ensure optimal adjustment of amount of dosed material

l  Pressing worm equipped with an automatic pushing out system (W-160, W-200)

l  Grinders equipped with peripheral device for separation of tendons and membranes (optional) and separator of poultry bones (optional)

l  Unique construction of pressing worms, worms in the production of CNC machining centers   from a single piece of steel by machining




技术参数

Type


w-130

W-160

W-200

diameter of throat

mm

130

160

200

capacity of hopper

dm3

360

360

450

power of pressing worm   drive motor

kW

13,5/20

25/34 or 28/38

37/53

power of drive motor   of loader

kW

1,1

1,1

1,1

output

kg/h

up to 3000

up to 9000

up to 12000

dimensions L/W/H

mm

2310/1750/3000

2650/1940/3250

3110/1990/3280

Weight

kg

1500

2300

3100
